BT136

glass passivated triac, T0-92, 600V, 3.1A2s, 4 A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~1.00

PartNumber:: BT136

Brand:: NXP Semiconductors - nxp | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. handy chan's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-19

From Other Seller

Part Number:BT136
US $0.20 - 1.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
PCM63P-K

US $18.00 - 25.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BT136 is a glass passivated triac in a plastic envelope. The device is intended for use in applications requiring high bidirectional transient and blocking voltage capability and high thermal cycling performance. Thypical applications of the BT136 include motor control, industrial and domestic lighting, heating and static switching.

Parametrics

BT136 absolute maximum ratings: (1)VDRM, Repetitive peak off-state voltages: 600V; (2)IT(RMS), RMS on-state current: 4 A when full sine wave; Tlead≤51℃; (3)ITSM, Non-repetitive peak full sine wave; Tj = 25℃ prior to on-state current surge: 25A when t=20ms; (4)I2t, I2t for fusing t = 10 ms: 3.1A2s; (5)dIT/dt Repetitive rate of rise ofon-state current after triggering, ITM = 1.5 A; IG = 0.2 A, dIG/dt = 0.2 A/ μs, T2+ G+: 50 A/μs; T2+ G: 50 A/μs; T2- G: 50 A/μs; T2- G+: 10 A/μs; (6)IGM, Peak gate current: 2 A; (10)VGM, Peak gate voltage: 5 V; (7)PGM, Peak gate power: 5 W; (8)PG(AV), Average gate power over any 20 ms period: 0.5 W; (9)Tstg, Storage temperature: -40 TO 150℃; (10)Tj, Operating junction temperature: 125℃.

Features

BT136 features: (1)VDRM, repetitive peak off-state voltages: 600V; (2)IT(RMS), RMS on-state current: 4A; (3)ITSM, non-repetitive peak on-state current: 25A.
